M30 Inductive Proximity Sensor

Get a Price/Quote

MOQ : 1 Piece

M30 Inductive Proximity Sensor Specification

Application
Object Position Sensing, Counting, Automation Systems

Mounting Thread
M30

Power Consumption
15mA

Interface
3-wire or 4-wire DC

Mounting Type
Threaded (Flush/Non-Flush)

Response Time
< 2 ms

Spectral Range
N/A (Inductive)

Features
Short-circuit Protection, Polarity Protection

Sensitivity
Adjustable

Housing Material
Nickel-plated Brass

Measurement Range
Sensing Distance up to 15mm

Ingress Protection
IP67

Sensor Type
Inductive

IP Rating
IP67

Operating Temperature
-25C to +70C

Wireless
No

Cable Length
Typically 2 meters (or Connector Type)

Signal Type
Digital Output

Product Type
Inductive Proximity Sensor

Material
Metal Body

Input
10-30V DC

Output
PNP/NPN, NO/NC (Depending on model)

Function
Object Detection

Usage
Industrial Automation, Position Sensing

Accuracy
High Repeatability

Resolution
Standard Resolution

Voltage
10-30 V DC

Weight
Approx. 150g

Storage Temperature
-40C to +85C

Housing Length
Typically 60-80mm

Vibration Resistance
10-55 Hz, 1.5mm double amplitude

Operating Mode
Normally Open (NO) or Normally Closed (NC)

Mechanical Life
>10 million operations

Ambient Humidity
35% - 95% RH

Switching Frequency
Up to 400 Hz

Connector Type
M12 Connector

M30 Inductive Proximity Sensor Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Cash in Advance (CID)

Supply Ability
100 Pieces Per Month

Delivery Time
2-5 Days

Main Domestic Market
All India

M30 Inductive Proximity Sensor About

Get the grandiose M30 Inductive Proximity Sensor and experience top-tier efficiency in industrial automation! Highlighted by monumental durability-mechanical life exceeds 10 million operations-and built with robust nickel-plated brass, this sensor delivers stellar accuracy, high repeatability, and adjustable sensitivity. Ideal for object detection and position sensing, it operates from 10 to 30V DC and offers exceptional ingress protection (IP67). Secure this deal and enhance your process control with versatility: NO/NC, PNP/NPN outputs, and switching frequencies up to 400 Hz. Available for immediate supply across India from reputed distributors and manufacturers.

Commercial Applications & Specialized Features of M30 Inductive Proximity Sensor

The M30 Inductive Proximity Sensor stands out in automated manufacturing, assembly lines, and quality control systems. Designed for object position sensing and counting, it excels in harsh industrial environments thanks to IP67 protection and vibration resistance. Flexible mounting options-flush or non-flush-enable versatile installation. With high repeatability and adjustable sensitivity, it ensures precision in material handling, packaging automation, and conveyor systems. Its top-tier features make it a staple for process optimization in commercial facilities.

Market Value, Payment Terms, and Supply Capacity for M30 Sensor

Market value is driven by the sensor's high performance and reliability. Competitive asking prices are available for bulk or distributor orders. We ensure quick dispatch across domestic and international markets, targeting regions with advanced automation requirements. Payment terms are flexible and cater to both new and longstanding partners. With impressive supply capacity, we efficiently fulfill demands for large or urgent projects, contributing to high customer satisfaction in dynamic export markets.

FAQ's of M30 Inductive Proximity Sensor:

Q: How does the M30 Inductive Proximity Sensor enhance industrial automation?

A: The M30 sensor provides reliable object detection and position sensing with high repeatability, ensuring accuracy and process efficiency in automated systems such as conveyor lines, assembly stations, and packaging machinery.

Q: What are the primary applications for the M30 Inductive Proximity Sensor?

A: This sensor is ideal for object detection, position sensing, counting, and safety monitoring in industrial automation, manufacturing, packing, and material handling operations.

Q: Where can the M30 Inductive Proximity Sensor be installed?

A: It can be installed in commercial or industrial environments requiring robust, non-contact object detection. The sensor's threaded housing allows for easy flush or non-flush mounting on machinery, conveyor systems, or production lines.

Q: What makes the M30 sensor suitable for harsh environments?

A: Its nickel-plated brass housing, IP67 ingress protection, and vibration resistance make the sensor ideal for wet, dusty, or demanding industrial conditions.

Q: How is the M30 Inductive Proximity Sensor powered and connected?

A: The sensor operates on a 10-30V DC input and supports 3-wire or 4-wire DC connections via M12 connectors or standard cabling, depending on the chosen model.

Q: What is the process for ordering and receiving the M30 sensor?

A: Customers can request quotes based on specific models and required quantities. Upon confirmation and receipt of payment, sensors are quickly dispatched to the required location, ensuring timely delivery.
